2023 INFINITI QX50 | Luxury SUV

Engine

Type

KR20DDET

Camshaft design

DOHC

Configuration / Orientation

Transverse mounted

Cylinders / Configuration

4 / Inline

Block / Cylinder head composition

Aluminum / Aluminum

Displacement

2.0 liter/1,970 - 1,997 cc

Horsepower

268 hp @ 5,600 rpm

Torque

280 lb-ft @ 1,600-4,800 rpm

Bore & stroke (mm)

84.0 x 90.1 (8.0:1 CR) – 84.0 x 88.9 (14.0:1 CR)

Compression ratio (:1)

8.0 – 14.0 (variable)

Maximum engine speed (redline rpm)

6,000 rpm

Induction system

Turbocharged

Fuel delivery system

Direct and port injection

Valvetrain

4 valves per cylinder,
Continuously Variable Valve Timing

Mounts

Front
Rear

2 solid (active control type)
2 liquid-filled, left and right side

Recommended fuel

Premium unleaded

Emission certification level

Tier3 Bin70/ LEV3-ULEV70

Exhaust

Dual system with sub and main mufflers

Transmission and Drive System

Drive configuration

Front-wheel drive or Intelligent All-Wheel Drive

Transmission type

Xtronic continuously variable transmission with manual shift mode and Downshift Rev Matching

CVT high ratio coverage (:1)

6.3

Reverse gear (:1)

0.745

Final drive (:1)

5.846

Transmission oil cooler and upsized radiator fan

QX50 AUTOGRAPH only

Vehicle Dynamic Control

S

Hill Start Assist

S

Brakes

Front

13.0-inch x 1.3-inch power-assisted vented disc

Rear

12.1-inch x 0.6-inch power-assisted vented disc

Parking brake

Electronic, switch on console

Electronic brake force distribution

S

Anti-lock braking system

Suspension and Steering

QX50 PURE

QX50 LUXE

QX50 SPORT

QX50 SENSORY

QX50 AUTOGRAPH

Body type

Corrosion-resistant and high-strength steel unibody construction, aluminum-alloy hood

Front suspension

MacPherson strut front suspension with aluminum-alloy upper and lower aluminum/steel subframe construction

Rear suspension

Independent multilink with stabilizer bar

Speed-sensitive variable assist steering

S

Shock absorbers

Twin tube front, monotube rear

Steering ratio Rack EPS (:1)

15.3

Curb-to-curb turning circle diameter (ft)

36.4

Exterior Dimensions (in)

Wheelbase

110.2

Overall length

184.7

Overall width

74.9

Overall height

66.0

Front track width

64.4

Rear track width

19-inch wheels
20-inch wheels

64.2
63.8

Minimum ground clearance

8.6

Coefficient of drag (Cd)

0.32

Angle of approach (degrees)

17.2

Angle of departure (degrees)

23.9

Breakover angle (degrees)

19.0

Trunk liftover height

27.7

Step-in height, front/rear

17.2/17.7

Capacities & Volume

Seating capacity

5

Passenger compartment volume (cu. ft.)

53.1 w/moonroof, 54.4 w/o moonroof

Cargo volume with 2nd row up (cu. ft.)

31.1 w/moonroof, 31.4 w/o moonroof

Cargo volume with 2nd row folded (cu. ft.)

64.4 w/moonroof, 65.1 w/o moonroof

Total interior volume (cu. ft.)

133.3 w/moonroof, 135.8 w/o moonroof

Fuel tank (gals.)

16.0

Engine oil (qts.)

5.0

Engine coolant (qts.)

8.0

Towing capacity (lbs.)

3,000 (QX50 AUTOGRAPH only)

Interior Dimensions (in)

Headroom

Front seats

40.0 (41.0 without moonroof)

Rear seats

38.4 (39.1 without moonroof)

Legroom

Front seats

39.6

Rear seats

38.7

Shoulder room

Front seats

57.9

Rear seats

57.1

Hip room

Front seats

55.6

Rear seats

53.8

Wheels and Tires

QX50 PURE

QX50 LUXE

QX50 SPORT

QX50 SENSORY

QX50 AUTOGRAPH

19 x 7.5-inch aluminum-alloy wheels (silver painted)

S

-

-

-

20 x 8.5-inch aluminum-alloy wheels (silver painted and machine finished)

-

-

-

S

20 x 8.5-inch aluminum-alloy wheels (dark painted and machine finished)

-

-

S

-

-

All-season, run-flat P235/55R19 tires

S

S

-

-

-

All-season, run-flat P255/45R20 tires

-

-

S

S

S

Tire pressure monitoring system-Direct sensor type

S

Easy-fill tire alert

S

Exterior Features and Options

QX50 PURE

QX50 LUXE

QX50 SPORT

QX50 SENSORY

QX50 AUTOGRAPH

LED headlights (low/high beam)

S

Unique cube design headlights

-

-

-

S

S

LED signature daytime running lights

S

Front LED fog lights

-

-

S

S

S

Adaptive front lighting system

-

-

-

S

S

LED taillights

S

Body-color, auto-folding outside mirrors

S

Black, auto-folding outside mirror caps

-

O

-

-

-

Auto-dimming outside mirrors

-

-

-

S

S

Heated outside mirrors

S

Reverse tilt-down mirrors

-

S

S

S

S

Mirror memory function

-

S

S

S

S

Panoramic moonroof with power open/tilt and power sunshade

-

S

S

S

S

Silver painted oof rails

-

S

-

S

S

Black painted roof rails

-

-

S

-

-

Body-colored door handles with chrome accents and LED welcome lights

S

UV-reducing, noise-insulated windshield

S

Power liftgate

S

Motion-activated liftgate

-

S

S

S

S

Rear passenger window sunshades

-

-

-

-

S

Remote engine start

S

Interior Features and Options

QX50 PURE

QX50 LUXE

QX50 SPORT

QX50 SENSORY

QX50 AUTOGRAPH

Leatherette-appointed seats

S

-

-

-

-

Leather-appointed seats

-

S

-

-

-

Semi-aniline leather-appointed seats

-

-

S

S

-

Semi-aniline, quilted leather-appointed seats

-

-

-

-

S

Driver’s Seat

8-way power

S

2-way power lumbar

S

-

-

-

-

4-way power lumbar

-

S

S

S

S

Heated

-

S

-

-

-

Heated and cooled

-

-

S

S

S

Entry/exit assist

-

S

S

S

S

Front Passenger’s Seat

8-way power

S

4-way power lumbar

-

-

-

S

S

Heated

-

S

-

-

-

Heated and cooled

-

-

S

S

S

Rear Seats

60/40-split folding, recline and fold-flat bench seat

S

Heated (outboard
positions only)

-

-

-

S

S

Interior Accents

Leather-wrapped steering wheel

S

Dark painted aluminum accents

S

S

-

-

-

Black aluminum accents

-

-

S

-

-

Open pore maple wood accents

-

-

-

S

S

Gray Tricot headliner

S

S

-

S

-

Graphite Tricot headliner

-

-

S

-

-

Ultrasuede headliner

-

-

-

-

S

Interior Features

Frameless auto-dimming rearview mirror

S

Single sun visors with illuminated vanity mirror and extender

S

Full-color vehicle meter, 7-inch display

S

Trip computer

S

Manual tilt and telescoping steering wheel

S

S

S

-

-

Power tilt and telescoping steering wheel

-

-

-

S

S

Two-driver steering wheel memory

-

-

-

S

S

Heated steering wheel

-

-

S

S

S

Dual-zone Automatic Temperature Control system

S

S

S

S

-

Tri-zone Automatic Climate Control System with grape polyphenol filter

-

-

-

-

S

Enhanced interior ambient lighting

-

-

S

S

S

Rear Door Alert

S

Rear heating ducts under front seats

S

Rear HVAC vents

S

Audio and Infotainment

QX50 PURE

QX50 LUXE

QX50 SPORT

QX50 SENSORY

QX50 AUTOGRAPH

INFINITI InTouch™ dual HD display system with LCD/VGA 8-inch upper and 7-inch lower touchscreens

S

INFINITI InTouch™ Services

S

Siri® Eyes Free

S

Wireless Apple CarPlay® integration

S

Android Auto™ integration

S

Wireless device charging pad

S

Six-speaker audio system

S

S

-

-

-

Bose® Premium Audio System with 12 speakers

-

O

S

-

-

Bose® Performance Series Audio System with 16 speakers

-

-

-

S

S

Head-up display

-

-

-

S

S

HD Radio® Technology

S

Streaming audio via Bluetooth®

S

Voice Recognition

S

SiriusXM® Radio (Subscription
required, sold separately)

S

Wi-Fi hotspot

S

Four USB ports (two Type-A, two Type-C)

S

Navigation with detailed real time Premium Traffic info, 3D building graphics, & seamless turn-by-turn directions, SiriusXM® Travel Link and SiriusXM® Traffic

-

-

S

S

S

Safety, Security and
Driver-Assist Features

QX50 PURE

QX50 LUXE

QX50 SPORT

QX50 SENSORY

QX50 AUTOGRAPH

INFINITI Advanced Air Bag System

S

Rear seat-mounted side-impact supplemental air bags

S

3-point ALR/ELR (driver ELR only) front seat belts with pretensioners and load limiters and adjustable upper anchors

S

3-point rear seat belts (ALR/ELR all positions)

S

Forward Emergency Braking with pedestrian detection

S

Predictive Forward Collision Warning

S

Lower Anchors & Tethers for CHildren (LATCH)

S

INFINITI Vehicle Immobilizer System

S

RearView Monitor

S

S

-

-

-

Around View Monitor® with Moving Object Detection

-

-

S

S

S

Blind Spot Warning and Intervention

S

Lane Departure Warning and Intervention

S

ProPILOT Assist

S

Intelligent Cruise Control with Full Speed Range

S

Rear Automatic Braking

S

High Beam Assist

S

Traffic Sign Recognition

-

-

S

S

S

Rear Automatic Braking

S

Rear Cross Traffic Assist

S

Vehicle Dynamic Control (VDC) with Traction Control System

S

Packages and Options

QX50 PURE

QX50 LUXE

QX50 SPORT

QX50 SENSORY

QX50 AUTOGRAPH

Bose® 12-Speaker Premium Audio Package: Bose® Premium Audio System with 12 speakers with metallic speaker grilles on tweeters

-

O

-

-

-

QX50 PURE

QX50 LUXE

QX50 SPORT

QX50 SENSORY

QX50 AUTOGRAPH

FWD

AWD

FWD

AWD

FWD

AWD

FWD

AWD

AWD

Curb Weight (lbs)
Front
Rear
Total

2,308
1,541
3,849

2,359
1,620
3,979

2,326
1,616
3,942

2,374
1,695
4,070

2,346
1,634
3,979

2,396
1,720
4,116

2,361
1,656
4,017

2,405
1,731
4,136

2,401
1,779
4,180

Weight distribution
(% FR/RR, with driver)

60/40

60/40

60/40

60/40

60/40

60/40

60/40

60/40

60/40

GVWR

4,916

5,075

4,916

5,075

4,916

5,075

4,916

5,075

5,075

EPA Est. Fuel Economy (mpg)

QX50 FWD

QX50 AWD

City
Highway
Combined

23
29
26

22
28
25
